THERMAL PRECISION FOR HIGH-PURITY POLYSILICON PROCESSING

polysilicon production Application

Stable Heat Transfer Solutions For Chlorosilane Synthesis, Multi-Column Distillation, And Continuous Utility Control

In Polysilicon Production, thermal management is critical long before silicon deposition begins. In the Siemens route, metallurgical-grade silicon is first converted to trichlorosilane (TCS), a volatile intermediate with a boiling point of 31.8°C, then purified through energy-intensive multi-column distillation before final deposition on electrically heated filaments at up to 1,150°C. Because TCS purity directly determines polysilicon quality, reliable heat-transfer fluids are essential for chlorosilane synthesis, preheating, reboilers, condensers, hydrogenation loops, and closed-loop utility systems. Eurotherm 181 offers a vapor-phase operating range of -80 to 315°C, a boiling point of 181°C, and very low viscosity for even heat distribution in responsive low-temperature and overhead service Eurotherm 330 delivers -49 to 315°C performance with 4.04 mm²/s viscosity at 40°C, ideal for cold start-up and flexible circulation. Eurotherm 320, rated from -30 to 320°C with 9.8 mm²/s viscosity, provides cost-effective stability for mainstream synthesis and distillation units. Eurotherm THT extends to 350°C with hydrogenated terphenyl chemistry, low system pressure, and outstanding thermal stability for higher-duty hot-oil loops.RÜTGERS Ruetasolv BPD, operating from -55 to 350°C, adds low-pour-point, low-viscosity, long-life performance for demanding continuous plants seeking lower maintenance and dependable 24/7 operation.

Recommended Products
